Redarc TVMS Rogue

A compact and flexible power control solution for caravan, camper and truck applications.

Please be advised that in order for the TVMS Rogue to operate, a RedVision Display (DISP4300-RC) is required (Sold Separately.)

TVMS Rogue is compatible with RedVision Display units (DISP4300-RC) manufactured from January 2023, serial numbers beginning with 23. Displays manufactured from July 22 to Jan 23 (serial numbers beginning 2207 – 2212) are upgradable.

RedVision by REDARC provides an unprecedented level of control and automation to your truck, caravan, camper, RV or work vehicle. Control accessories such as lights, fridges, TVs and inverters via the physical screen or your Bluetooth connected mobile device.

At just 1inch thick with in-built smart fusing, the TVMS Rogue offers a small footprint, great for vehicles with limited space. Dimmable outputs make the Rogue RedVision system ideal for lighting and low powered devices such as fridges and fans.

When paired with a Manager30 (sold separately) and RedVision Display* (sold separately), TVMS Rogue provides real time and accurate state of charge, power input/output and ambient temperature information. Two analogue tank level inputs offer accurate monitoring of multiple tanks and the Rogue is compatible with most common tank level sensors.

CONTROL

The TVMS Rogue allows complete control of multiple on-board devices including lights, fans, fridges, and pumps. Each of its 10 output channels include dimming and the built-in switch inputs make the Rogue perfect for lighting circuits.

With the Rogue connecting to up to 8 physical switches, control is not just limited to the RedVision screen or app. It enables lights to be controlled from each room of an RV or for the addition of reed switches to trigger lights when opening a door for example.

AUTOMATION

Save time and energy by using RedVision to automate those mundane tasks. With the press of a button, switch off everything except for your fridge or power down non-essential loads when your batteries are running low.

For the complete RedVision solution, pair your TVMS Rogue with the Manager30 battery management system. Find out more here.

FEATURES:

• 10x 10A dimmable outputs
• 8x inputs allow for use with physical switches
• Compact size
• On-board smart fuses
• Streamlined installation and configuration
• Fully programmable*
• Accurate analogue tank level inputs

SCREEN COMPATIBILITY

TVMS Rogue is compatible with DISP4300-RC models manufactured from January 2023 (serial numbers beginning with “23”). Displays manufactured from July 2022 to January 2023 are upgradeable (serial numbers “2207” to “2212”).

APP AVAILABILITY

*TVMS Rogue Configurator app available now for iOS but coming soon for Android. The configurator app is only required for initial installation and set up. The user app is available now for both iOS and Android.
